| ENGINE |
| Type |
Greaves600W, 4 stroke, naturally aspirated, direct
injection, water-cooled diesel engine |
| Engine capacity (cc) |
611 |
| Max engine output |
11 hp @ 3000 rpm |
| Max engine torque |
31 Nm @ 1600 – 1800 rpm |
| Fuel tank capacity (litres) |
10 |
| TRANSMISSION AND STEERING |
| Clutch |
Single plate dry friction diaphragm type |
| Gearbox |
TA 59 |
| Type |
4 speed manual transmission |
| Steering |
Mechanical steering |
| SUSPENSION |
| Front |
Mc Pherson strut |
| Rear |
Coil spring with semi trailing arm |
| Shock absorber |
Hydraulic double acting telescopic type |
| BRAKES |
| Front |
Drum brakes |
| Rear |
Drum brakes |
| WHEELS & TYRES |
| Type |
145 / 80 R 12 LT 6PR Radial |
| DIMENSIONS |
| Wheelbase (mm) |
1650 |
| Vehicle dimensions (l*b*h) (mm) |
2960 x 1512 x 1800 |
| WEIGHTS |
| GVW (Kg) |
1110 |
| Payload (Kg) |
685 |
| PERFORMANCE |
| Grade ability |
22% |
| Top speed (kmph) |
50 |
